Capacity | 1.0HP |
Cooling Capacity | 10,000 (1,250~11,109) Btu/h |
Energy Efficiency Star Rating | 4 Star |
Warranty | 2 Years (Full) |
Warranty | 5 Years (Compressor) |
Indoor Unit | |
Indoor air flow (H) | 600 (353) m3/h(cfm) |
Indoor Sound level (Hi/Mi/Lo/Si) | 39.5/34.5/31.5/-- |
Product Dimensions (W*D*H) | 813 x 201 x 289 mm |
Packing Dimensions (W*D*H) | 870 x 270 x 365 mm |
Net/Gross Weight (kg) | 7.8/9.8 |
Outdoor unit | |
Outdoor sound level (dB(A)) | 52 |
Dimension(W*H*D) | 668 x 252 x 469 mm |
Packing Dimensions (W*D*H) | 765 x 270 x 515 mm |
Net/Gross Weight (kg) | 17/18.6 |
Refrigerant piping | |
Liquid side/ Gas side | 6.35/ 9.52(1/4"/3/8") |
Max. refrigerant pipe length | 25 |
Misc | |
Refrigerant Charge | R32/360g |
Design pressure(145psi=1MPa )(L/H) (psi) | 4.3/1.7 |
