| SPECIFICATIONS | |
| • Model | RWF-W2035UVBKH(K) |
| • Voltage/ Frequency | 220V-240V/50-62Hz |
| • Type | Bottom Loading |
| • Heating Method | External heating Element |
| • Heated water temperature ( ํC) | < 90 ํC |
| • Hot Tank dimension (ID x length) (mm.) | φ100 *130 (1.02L) |
| • Heated water capacity min at 25 ( ํC) Ambient (L/hr) | 4 L/H |
| • Hot Water | ≥ 1.2 L/Min |
| • Water bottle position | SUS304 |
| • Chilled water temperature - normal ( ํC) | 6-9 °C |
| • Cold Tank dimension (ID x length) (mm.) | φ166 x183 (3.6L) |
| • Cooling Method | Compressor |
| • Refrigerant type and weight | R134a/32g |
| • Chilled water capacity min at 25 ( ํC) Ambient (L/hr) | 2.5 L/H |
| • Chilled water | ≥ 1.2 L/Min |
| • Cold water tank material | SUS304 |
| • Dimension (WxDxH) (mm.) | 310 x 346 x 1040 |
| • Net Weight (kg.) | 15 Kg |
